System D
Mini DAQ
Block Diagram
FPGA with RAM
| FPGA | Power | RAM |
|---|---|---|
| efinix Ti60F100 | 1.1V Core 3.3V IO |
256Mb HyperRAM / 64Mb EEPROM |
| GoWin | 1.2V Core 3.3V IO |
64Mb~128Mb SDRAM / 32Mb EEPROM |
Zynq Mode
Zynq Mode:
1.Stand alone System
2.Store daq data in SDCard
3.Stream daq data from ethenet
4.Easy to run in parallel
5.Support KB/Mouse and LCD Screen
Pi 5 Mode
Pi 5 Mode:
1.Same as Zynq, except use Pi 5
2.Develop Linux App is more easy on Pi
Price Table
| Board | FPGA | FT601 | AD7980 | AD5662 |
|---|---|---|---|---|
| Mode 1 (efinix Ti60F100 ) | 40USD | 8USD | ||
| Zynq XME0715 | 160USD | X | ||
| Artix 7 XME0712 A35T | 135USD | (8USD) | ||
| Artix 7 A35T | 60USD | X |
